3.3V/5V MB102 Breadboard Power Supply Module

The 3.3V/5V MB102 Breadboard Power Supply Module is a versatile accessory tailored for the mb102 breadboard that offers dual 5V and 3.3V power rails. It's designed to securely integrate with standard mb 102 breadboard connections and can efficiently handle input voltages of 6.5V to 12V. This breadboard power supply module 3.3 v 5v features reverse polarity protection and boasts an onboard power switch for user-friendly operation, allowing for both 3.3V and +5V outputs. Additionally, the breadboard power supply module is ideal for a wide range of applications, ensuring stable power without requiring additional sources.

Key Features - Breadboard Power Supply Module

• Breadboard power supply module, compatible with 5V, 3.3V, providing reliable power for a breadboard esp8266 project.
• Input voltage: 6.5-12 V (DC) or USB power supply, perfect for breadboard power supply arduino tasks.
• Output voltage: 3.3V/5V can switch over, meeting the needs of 3.3 v 5v power supply.
• Maximum output current: <700 ma, ideal for breadboard buzzer applications.
• Fluctuation two road independent control can switch over to 0 V, 3.3 V, 5 V.
• On-board two groups of 3.3V, 5V DC output plug pin, convenient for atmega328 on a breadboard use.
• Compatible with breadboard mb102: Easily mounts onto standard MB102 solderless breadboards.
• Onboard Power Switch: Allows for easy on/off control while supporting a 5v breadboard power supply.
• LED Power Indicators: Displays active status of the output voltages, enhancing your esp8266 on breadboard experience.
• Extended Pins: Facilitates easy connectivity with the breadboard power rails.

Applications

The 3.3V/5V MB102 Breadboard Power Supply Module is ideal for powering your electronic circuits and components during testing and prototyping on a breadboard. This breadboard power module is essential for Arduino projects, and its ca 1235 buck converter module capability extends its utility to ESP8266 integrations and low-voltage digital circuits. For any project requiring a consistent 12v breadboard power supply, it's a vital component for both hobbyists and engineers. Additionally, it's suited for experimental configurations in educational settings and hobby projects, making it a must-have tool for enthusiasts working with the mb102.

Technical Specifications

How to Use

To use the Breadboard Power Supply Module, insert the module into the top of your mb102 breadboard power supply module with the pins aligned to the power rails. Connect the input to a 6.5-12V DC source using either the DC barrel jack or a USB power supply. To achieve optimal results with your arduino mb102 projects, set the desired output voltage by using the onboard switches to choose between 3.3V or 5V. Ensure all connections are secure before powering your circuit. Use the power switch to turn the module on, and the LED indicator will illuminate to show the status. Refer to the pinout diagram for additional connection details to enhance usage with mb102 power supply module.

Package Includes

• 1 x MB102 Breadboard Power Supply Module

Additional Resources

Videos Tutorial

Watch our comprehensive video on using the mb102 breadboard power supply and discover how it supports 3.3 v power supply module projects efficiently.
