PL2303 PL2303HX USB To TTL(Serial) Converter Module – 5 Pin
This is the pl2303 usb to ttl converter module, designed to provide reliable and high-speed data transfer for your electronic projects. As a versatile usb to ttl module, it integrates an imported controller RS232 TTL with a 500mA self-recovery fuse that stabilizes flash memory and provides protection during use. Built around the Prolific PL2303HX chip, it ensures the efficient conversion of usb ttl signals. Its unique design features two data transmission indicators to monitor real-time data transfer status, and a protective, transparent heat-shrinkable sleeve that insulates the PCB against material shortcuts. Crafted to be a ttl to usb converter, it reserves 3.3V and 5V pin interfaces to easily adapt to different voltage systems, offering compatibility with various operating systems, including Windows and Linux. Ideal for both hobbyists and professionals, this usb ttl adapter supports applications like upgrading satellite set-top boxes, routers, HDDs, and broadband modems, as well as other devices requiring serial communication.
Key Features - USB to TTL Converter
- Imported Controller: Ensures stability and high-speed performance, making this pl2303hx usb ttl adapter highly reliable.
- Data Transmission Indicators: Monitor real-time data status seamlessly, crucial for a usb to ttl cable setup.
- Voltage Compatibility: Supports 3.3V and 5V power systems, which are central to the usb to rs232 ttl pl2303hx module’s versatility.
- Heat-Shrinkable Sleeve: Provides insulation and protection, essential for maintaining a safe uart ttl converter configuration.
- Electrostatic Packaging: Protects the board pre-use, which is vital for any cp2102 usb to ttl applications.
- Plug-and-Play Design: No additional power supply required, powered via USB port, ideal for usb to ttl adapter utilization.
- Operating System Compatibility: Compatible with Windows and Linux, making it a pl2303hx usb to ttl solution with broad reach.
- Baud Rate: Supports up to 1 Mbps for efficient data transfer, a key feature for any ttl uart project.
Applications
The pl2303hx usb to ttl module is highly versatile and can be used in a variety of applications. For instance, it is often used for upgrading satellite set-top boxes and routers, essential in ttl to usb projects. It's an essential tool for those looking to update firmware on HDDs or modems, primarily utilized within repair shops or development teams engaged in software updates involving usb ttl signals. This module also supports serial communication tasks with devices like cell phones and GPS devices, serving as a ttl to usb converter commonly utilized by developers and electronic hobbyists. It is commonly used in interfacing PCs with microcontroller boards, suitable for programming, prototyping, and debugging tasks where a uart ttl converter is necessary.
Technical Specifications
Product Specification | Value |
---|---|
Model Type | Converter, also termed as a pl2303 usb to ttl converter |
Operating Voltage (V) | 3.3 to 5 |
Model No. | PL2303HX, often associated with usb to ttl cable setups |
Length (mm) | 52 |
Width (mm) | 15.5 |
Height (mm) | 6.5 |
Weight (g) | 5 |
Baud Rate | Up to 1 Mbps, as expected in applications of waveshare usb to rs232 485 ttl setups |
Chipset | Prolific PL2303HX |
Interface | USB to Serial TTL (5-pin), akin to 232 to ttl connectivity solutions |
Power Supply | Powered via USB port |
How to Use
To use the pl2303hx usb to ttl module, connect it to your computer using a USB cable. Ensure the driver is properly installed to facilitate communication; modern operating systems often recognize it automatically, especially with pc pl2303hx configurations. Connect the TTL serial end (5-pin connector) to the device requiring serial communication, ensuring RX and TX lines are crossed (RX to TX and TX to RX). Utilize the reserved 3.3V and 5V pin interfaces as needed for your specific project requirements. Observe the data transmission indicators to monitor live transfer rates and performance in your ttl to usb setup. Always ensure the workspace is properly insulated to prevent undesired shorts, leveraging the protective sleeve benefits. Adjust the baud rate settings in your software to match the required communication speed of the device.
Package Includes
- 1 x PL2303 PL2303HX USB To TTL Module
Additional Resources
Download DatasheetLearn more about USB to TTL Converter and pcm pl2303hx series
