Micro SD Card Reader Module for Microcontrollers - Arduino

Add the Desired memory to your Arduino project with a versatile sd card reader, suitable for storing data, media, etc. The SD Card Reader Module, often referred to as a sandisk card reader, provides a seamless solution for data transfer to and from a standard SD card. This sdxc card reader is directly compatible not only with Arduino but can also be used with other microcontrollers. Its SPI interface is compatible with any card reader for sd card and uses a 5V or 3.3V power supply, making it perfect for Arduino UNO/Mega projects. Additionally, this card reader for memory card features LED indicators for power and read/write operation status, enhancing project feedback visibility. Its applications include data loggers, audio, video, and graphics.

Key Features - SD Card Reader Module

• Power Supply: 4.5V – 5.5V, ideal for sd card and reader integration
• 3.3V Voltage Regulator Circuit included in sd card and card reader
• Positioning Holes: M2 with 2.2mm diameter, fitting small sd card reader setups
• Control Interface: GND, VCC, MISO, MOSI, SCK, CS
• Compatible with Arduino sd memory card adapter and other MCUs
• Supports standard Micro SD cards, perfect as a micro sd card reader
• LED indicators for operation status, useful for camera card reader functions

Applications

The SD Card Reader Module shines in various applications. It serves as a data logger, capturing sensor data for projects requiring time-stamped data using an sd chip reader. It's perfect for multimedia projects like audio and video players or even simple digital photo storage with a micro sd reader. In educational settings, it assists students or hobbyists in learning about interfacing microcontrollers with large storage mediums using sd and micro sd card reader setups. Its compact form is ideal for portable and space-constrained applications, fitting for a micro sd card and reader. Additionally, it finds use in expanding memory for microcontroller projects and software development environments requiring external storage.

Technical Specifications

How to Use

Using the SD Card Reader Module is effortless, whether you're employing a module micro sd arduino or other setups. Connect the module to your microcontroller using its SPI interface pins (GND, VCC, MISO, MOSI, SCK, CS), as seen in many sd card module with arduino projects. Ensure your power supply is within 4.5V to 5.5V, suitable for arduino microsd card reader modules. Place an SD card into the reader slot, and initiate SPI communication as per your microcontroller's specifications. For Arduino, use libraries like 'SD' or 'SDFat' to read/write to the card. Ensure connections are secure before providing power. Here's an example circuit connection diagram:

• GND: Connect to ground
• VCC: Connect to power supply
• MISO: Connect to microcontroller’s MISO pin
• MOSI: Connect to microcontroller’s MOSI pin
• SCK: Connect to microcontroller’s SCK pin
• CS: Connect to a digital pin (often pin 10)

Package Includes

1 x SD Card Reader Module

Additional Resources

Videos Tutorial
